ZK-III China Electric Testing Durable Transformer Short Circuit Impedance Tester
Introduction:
Zk-III Circuit Impedance Tester is an instrument developed by our company for low-voltage short-circuit impedance measurement of transformers under field and laboratory conditions.
Standards:
- DIN: DIN 53438
- ISO: ISO 11925-2
- EN: EN 13501
- IEC: IEC 61730-2:2016
Application Field:
- Building Materials;
- Rail;
- Automotive Interior;
Features:
- Small size and lightweight.
- ZK-III Transformer Short Circuit Impedance Tester adopts voltage and current synchronous AC sampling and digital signal processing technology, and the measurement data is accurate.
- For three-phase transformers, the instrument can test the transformer by a three-phase simultaneous test and split-phase test: three-phase simultaneous test uses a three-phase power supply, and the three-phase parameters can be directly measured; split-phase test uses a single-phase power supply, After measuring the corresponding phases in sequence, the three-phase parameters are automatically converted.
- For single-phase transformers, the instrument has a single-phase transformer testing function, which can directly test its impedance parameters.
- The instrument has built-in non-power-down memory, which can store measurement data for a long time. The instrument has its own printer, large-screen LCD display, all Chinese menus, and operation prompts, and the operation is simple and intuitive.
Parameters:
| No. | Item Name | ZK-III China Electric Testing Durable Transformer Short Circuit Impedance Tester |
| 1 | Dimension | 395*295*175mm |
| 2 | Weight | 5kg |
| 3 | Power supply | AC 1A 50A AC 50V ~ 500V |
| 4 | Ambient temperature | -10ºC~40ºC |
| 5 | Tested Transformer Type | Single Phase and Three Phase Transformer |
Zk-III Circuit Impedance Tester Real Picture:
